Brushless Submersible DC Pump 12V 5W 300cm 240L/H IP68 AD20P-1230B

Name: Brushless Submersible DC Pump 12V 5W 300cm 240L/H IP68 AD20P-1230B
Brand: Aaenics Store
SKU: 5245
Price: 102 GHS
Availability: InStock

The AD20P-1230B Brushless Submersible DC Pump, 12V 5W, offers a 300cm head and 240L/H flow with IP68 waterproofing, perfect for Arduino-based aquariums and hydroponics.

GHS 130GHS 102

Description

The AD20P-1230B Brushless DC Pump is a compact, efficient submersible water pump designed for applications requiring reliable water circulation or lifting. Operating at 12V DC with a power rating of 5W, it delivers a maximum flow rate of 240 liters per hour (Qmax 240L/H) and a maximum head height of 300cm (Hmax 300), making it suitable for small-scale water transfer tasks. This brushless design ensures a long lifespan (over 10,000 hours), low noise (<45dB), and no commutation sparks, avoiding electromagnetic interference. With an IP68 waterproof rating, it is fully submersible and ideal for use in aquariums, hydroponic systems, garden fountains, and industrial cooling applications.

The pump features an engineering plastic housing, approximately 34x38x26mm in size, with an 8.5mm inlet and outlet diameter, and a power cord length of about 460mm (or 140-160mm in some variants) ending in a 5.5x2.1mm DC female jack for easy connection to a 12V power supply. It operates with a working current of around 400-500mA (adjusted for the 5W rating), and its brushless motor with a ceramic shaft ensures durability and quiet operation (typically <40dB in similar models). For Arduino integration, connect it to a 12V power source (e.g., via a relay or motor driver like the L298N), ensuring proper polarity, and use a flow sensor or microcontroller to monitor performance if needed. It functions effectively from 0°C to 75°C and is lightweight at approximately 75g.

Note: A heat sink or adequate water flow is recommended to prevent overheating, and the pump should be submerged during operation to maintain efficiency.
